VOOPOO UForce Replacement Coils

VOOPOO UForce Coils

VOOPOO UForce replacement coils are sold in packs of five and cover a wide wattage range across three coil series: the U series (parallel wire coils), the N series (mesh coils) and the D series (quad wire coils). Nine variants are available in total, spanning 0.13 Ohm to 0.6 Ohm and 24W to 130W.

All variants use organic cotton wicking, a gold-plated connection and a vertical coil structure designed to maximise flavour and wicking consistency. UForce coils are compatible with the UForce T1, UForce T2, DRAG 2, DRAG Mini, MOJO, TOO, Caliber and VMATE.

VOOPOO UForce Replacement Coils Key Features

• Pack of 5 coils
• Nine variants across three series: U, N and D
• U series: parallel wire coils, 0.15 to 0.4 Ohm
• N series: mesh coils, 0.13 to 0.3 Ohm
• D series: quad wire coils, 0.4 Ohm
• Organic cotton wicking on all variants
• Gold-plated connection
• Vertical coil structure for consistent wicking
• All variants sub-ohm DTL: no MTL option in the UForce range
• Compatible with UForce T1, T2, DRAG 2, DRAG Mini, MOJO and more

U Series: U2, U4, U6, U8

The U series uses parallel wire coils in a vertical orientation and is designed for high-wattage DTL vaping. Wicking is organic cotton throughout. The four U series variants cover a broad wattage range from 40W up to 130W, making them the most power-flexible coils in the UForce lineup.

• U2: 0.4 Ohm, 40 to 80W. Dual parallel coil. The lowest-wattage entry point in the U series and a good choice for vapers using devices that top out in the 40 to 80W range. Best results between 55 and 65W.
• U4: 0.23 Ohm, 50 to 120W. Quad parallel coil. Steps up vapour volume considerably over the U2. Works best between 60 and 80W and suits high-powered devices well.
• U6: 0.15 Ohm, 65 to 110W. Sextuple parallel coil. A high-power option with dense vapour output. Best between 80 and 90W.
• U8: 0.15 Ohm, 70 to 130W. Octuple parallel coil. The highest-power U series option, requiring devices capable of 70W or more. Best between 90 and 110W.

N Series: N1, N2, N3

The N series uses mesh heating elements rather than parallel wire construction, which produces more consistent flavour across the life of the coil and faster heat-up times at comparable wattages. All three N series coils are designed for DTL vaping with high-VG shortfills or freebase nicotine at no more than 10mg.

• N1: 0.13 Ohm, 50 to 100W. Single mesh coil. The lowest resistance in the entire UForce range. Well-suited to vapers who prioritise flavour clarity and cloud production at mid to high wattages. Best between 70 and 80W.
• N2: 0.3 Ohm, 45 to 80W. Dual mesh coil. A more accessible mesh option for vapers using mid-powered devices. Best between 55 and 65W.
• N3: 0.2 Ohm, 65 to 100W. Triple mesh coil. Sits between the N1 and N2 in terms of power requirement and vapour output. Best between 75 and 85W and a popular choice for flavour-focused DTL vapers on devices in the 65 to 100W range.

D Series: D4

The D4 is the sole D series variant, running at 0.4 Ohm with a recommended wattage of 50 to 90W. It uses a quad wire construction in a parallel arrangement rather than mesh and is best suited to vapers who prefer the characteristics of a wire coil over a mesh coil at mid to high wattages. Best results come between 65 and 75W.

P Series: P2

The P2 is the only lower-wattage option in the UForce range, running at 0.6 Ohm with a recommended wattage of just 24 to 28W. It uses a single mesh construction and is designed for vapers who want a mesh coil experience at significantly lower power than the N series. It is still a sub-ohm DTL coil and is not suited to nicotine salts at higher strengths.

N Series vs U Series: What Is the Difference?

The main difference between the N series and the U series is the heating element. U series coils use parallel wire construction, while N series coils use mesh. Mesh covers a larger surface area and heats more evenly, which generally produces more consistent flavour and a slightly faster heat-up time at the same wattage. The U series coils tend to suit vapers who prioritise raw vapour volume at very high wattages, while the N series suits vapers who prioritise flavour. The N3 and U4 are the most directly comparable variants: both sit in the mid-range of the lineup, but the N3's triple mesh construction typically delivers richer flavour than the U4's quad wire design at equivalent wattages.

Organic Cotton and Vertical Coil Structure

Every UForce coil uses Japanese organic cotton as the wicking material, which absorbs e-liquid cleanly without contributing off-flavours over the life of the coil. The vertical coil orientation ensures e-liquid feeds consistently into the wicking ports from all sides, reducing the risk of dry hits during extended use. Gold-plated connections on every variant ensure a clean, low-resistance contact with the tank base.

Compatible Devices and Tanks

VOOPOO UForce coils are compatible with the following devices and tanks:

• VOOPOO UForce T1 tank
• VOOPOO UForce T2 tank
• VOOPOO UForce tank
• VOOPOO DRAG 2
• VOOPOO DRAG Mini
• VOOPOO MOJO
• VOOPOO TOO and TOO Resin
• VOOPOO Caliber
• VOOPOO VMATE
• Any other VOOPOO device specifying UForce coil compatibility

What's in the Pack

• 5 x VOOPOO UForce coils (one variant per pack)
